1. Color Coated Roofing Sheet simple introduction
It is produced by direct application of a paint (after applying a treatment and,in most instances, a primer) onto steel sheet in a coil-coating line. Coil-line painting can be used to apply a paint coating directly on uncoated steel sheet or on metallic-coated steel sheet.
2. Color Coated Roofing Sheet features & properties
The strength of steel, corrosion resistance of a metallic coating and beauty and additional corrosion protection.
3. Color Coated Roofing Sheet main usage
An essential fabrication component, it is widely used in applications,where corrosion resistance is needed, such as outdoor building, marine.
4. Color Coated Roofing Sheet high technology
It is produced on high technology coil coating lines under rigid quality controls,this product has a painted finish that is uniform in color, gloss, texture and thickness, with excellent paint adhesion and durability.
5. Color Coated Roofing Sheet raw materials
(1) Hot dipped galvanized steel sheet
(2) Pre galvanized steel sheet
(3) Galvalume steel sheet
(4) Pre painted galvalume steel sheet
6. Color Coated Roofing Sheet technical processing
Hot rolled steel coil -->Cold rolled- >hot dipped galvanized/ galvalume/painted- > corrugated-->packing
| material | galvanized steel sheet |
| prepainted galvanized sheet |
| model No. | types of roof sheets |
| sheet thickness | normal use 0.3-0.6mm |
| length | any length,according to the transportation,generally less than 12m |
| color | standard color:red,blue,white,grey |
| special color:according to RAL color |
| characteristic | 1: weather proof |
| 2: heating insulation |
| 3: fireproof |
| 4: anti-rust |
| 5: sound insulation |
| 6: long life span:more than 15 years |
| advantages | 1. low foundation cost |
| 2. easy construction |
| 3. time saving |
| 4. labor saving |
| application field | 1: construction:prefabricated house,steel house,mobile house,modular house,villa,
bungalow design,portable house/carbin,ready made house,kiosk booths,steel building... |
| 2: container manufacturing |
| 3: household appliances and furniture |
| 4: vehicle and vessel manufacturing |
| 5: others,like machinery structual parts,maufacturing shells of motors and so on |
| packing | plastic film,pallet or as your request |
