JIS G 3302 / ASTM A924 Color Coated Steel Sheet Roll Of Aluminum Coil ISO Certificate
-- min order :5 ton or one coil
-- max order :10000t/month
-- Payment terms: T/T,L/C, D/A,D/P are the payment methods or negociated.
-- Delivery time :20-25 days to produce
--aftersale :the best aftersale service
Specification of galvalume steel coil
1. thickness of ppgi or ppgl:0.23mm-1.2mm, if you need other thickness, further discussion.
2. width of ppgi or ppgl:600mm, 914mm, 1000mm, 1200mm, 1220mm, 1250mm, if you need other width, further discussion
3. color of ppgi or ppgl: RAL color
4. zinc coating of ppgi or ppgl: 30-275g
5. paint film of ppgi or ppgl: further discussion
6. Any other requirements of ppgi or ppgl, further discussion
| Product |
galvalume coil/color coated galvanized steel coil sheet/zinc aluminium roofing sheet |
| Certificate |
ISO / CE / SGS |
| Standard |
JIS G 3302 / ASTM A924 / ASTM A653 / EN 10327 / EN10142 / GBT2518 |
| Steel Grade |
DX51D / DC51D / SGCC |
| Size |
Thickness: 0.15mm-3.0mm
Width: 914/1000/1219/1200/1250mm, etc
|
| Color |
All RAL colors |
| Coating |
Zinc coating: 60-180g/m2 G30 G40 G60 |
| Spangle |
Non spangle / Zero spangle / Small spangle / Regular spangle / Big spangle |
| Coil weight |
3-8MT/Coil |
| Coil ID |
φ508mm-φ610mm |
| Different types |
Hot dipped galvanized coil (GI coil), hot dipped galvalume coil (alu-zinc coated coils, GL coil), Pre-painted galvanized coil (PPGI), Pre-painted galvalume coil (PPGL) |
| Packing |
Kraft + plastic film + galvanized steel sheets + steel straps, or as per customers' requirements |
| Application |
Roofing sheets / corrugated sheets / waving sheets |
| Others |
MOQ: 20MT
Delivery: Within 15-30days after down payment or L/C arrived
Payment: T/T,L/C etc.
|
Embossed aluminium coil details:
1) The paint of embossed aluminium coil: PVDF(mainly), PE
2) Thickness of total coating: PVDF: More then 25 micron; PE, more then 18 micron.
3) Paint: PPG or Nippon.
4) Interior diameter: 405mm or 505mm
5) Width of embossed aluminium coil: From 30mm-1200mm, sheets are also available
6) Color: Panton, RAL or refer to customers' counter sample.
7) Coating hardness: (pencil hardness) more than 2H
8) Impact resistance: No cracking and peeling(50kg/cm, ASTMD-2794: 1993)
9) Flexibility(T-bend): No more than 2T
10) MEK resistance: More than 100
The base of embossed aluminium coil details:
1) Temper of embossed Aluminium Coil: H14, H16, H18, H24, etc.
2) Alloy of embossed Aluminium Coil: 1100, 1050, 3003, manily
3) Origin: China
4) MOQ: 5 tons each size
5) Lead Time of embossed Aluminium Coil: Within 20 days
6) The term of payment: T/T, irrevocable L/C at sight
7) Application of embossed Aluminium Coil: Internal wall and external wall, tile, fence, roof etc.
8) Remarks of diamond color coated Aluminium Coil: Specific requirement of alloy, temper or specification can be discussed at your request.
The advantage of our Stucco Embossed Aluminium Sheet
(1) As aluminium is both a stable and durable material, it provides excellent service as a roofing or cladding without the need of any protective coating.
(2) The changes in appearance will be consistent along an elevation.
(3) Acid-corrosion-resistance, long-lasting shine, beautiful patterns, anti-corrosion performance and stability, strong adhesion, impact resistance, non-toxic side effects, safety and environmental protection.
(4) The electro-oxidation can effectively remove residual oil and manual handling of fingerprints.
(5) Embossed finish can enhance the thickness and strength of aluminum.
Applications
